JCO-6000-ORN-B (Coming soon!)
NVIDIA Jetson AGX Orin™ AI Computer with 8-core/12-core Arm® Cortex®-A78AE v8.2 64-bit CPU, 4x EDGEBoost I/O Support
特徴
- 8-core/12-core Arm® Cortex®-A78AE v8.2 64-bit CPU
- LPDDR5 3200MHz on SOM. 32GB/64GB
- 1x HDMI, 3840 x 2160 @ 60Hz
- 1x GbE, 1x 10 GbE (Wake-on-LAN and PXE)
- 2x External SIM Socket, 1x Micro SD Socket
- 1x eMMC 5.1 Storage, 64 GB
- 1x M.2 (M Key, 2280, PCIe x4, Support NVMe)
- 1x USB 3.2 Gen 2, 1x USB Type C, 1x USB 2.0
- 8x DI + 8x DO with isolation
- 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
- Wide Operating Temperature -20°C to 55°C (60W CPU)
- Support GMSL 2 QUAD Port Mini Fakra, 8x Ports | 1280x720 @30FPS (optional)
- Up to 4x EDGEBoost I/O Support
-
製品概要The JCO-6000-ORN-B series is an ultra-rugged fanless edge AI industrial computer powered by NVIDIA Jetson AGX Orin modules (275 TOPS). It supports up to 8x GMSL2 cameras and includes up to 4x EDGEBoost I/O for USB3, PoE, and GigE vision cameras. This Edge AI computer also features remote management capabilities through an OOB module.
At C&T, we pride ourselves in providing competent edge computing solutions that deliver reliable performance while deployed in challenging industrial environments. Our flagship line of rugged-edge computers has achieved UL Listed and has been rigorously tested and validated for safety standards compliance: UL Listed (Pending), FCC/CE, E-Mark, EMC-Conformity including EN 50155. Test procedure: CB Scheme.
📥 Download JCO-6000-ORN series Product Brief -
